600V/1000V 1 input 1output
- · MODEL:
- MY-PV1/1
- · Country Of Origin:
- Zhejiang, China
- · Brand:
- mday
- · Material:
- Copper, PVC
- · Rated Current:
- 15a
- · Application:
- LED Touch Control, Automotive
- · Rated Frequency:
- 50Hz, 60Hz
- · Voltage:
- 600, 1000
Product Description
Mday’s PV DC combiner boxes - high quality, optimized, robust and efficient
For solar installations in the PV industry, reliability and availability are paramount. In systems with string inverters, our AC and DC combiner boxes provide optimal short-circuit and overvoltage protection. Furthermore, each string inverter can be easily isolated from the system to do maintenance tasks.
 |
DC MY-PV1/1 600V combiner box
Features/Benefits
* High reliability
With DC fuse, DC surge protection, DC circuit breaker or DC load isolation switch.
* Strong adaptability IP65 design, waterproof, dustproof, UV resistant. Strict high and low temperature test, wide range of uses. Simple installation, simplified system wiring, convenient wiring, the box is cold- molded steel and other metal materials.
* Flexible configuration For use in monocrystalline silicon solar modules, polycrystalline silicon solar modules, thin film solar modules. Rated current of photovoltaic fuses.
|
 |
 |
MY-PV1/1 600VDC fuse 32A * 2 pcs DC MCB 2P * 1 pc
DC SPD 2P * 1 piece
|
MY-PV1/1 1000VDC fuse 32A * 2 pcs DC MCB 4P * 1 pc
DC SPD 2P * 1 piece
|
 |
 |
 |
| DC Fuse | DC MCB | DC SPD |
|
Name
|
MY-PV1/1
|
|
|
Electrical parameters
|
||
|
System maximum DC voltage
|
600V
|
1000V
|
|
Maximum input current per string
|
15A
|
|
|
Maximum input string
|
1
|
|
|
Maximum output switch current
|
16A/20A
|
|
|
Inverter MPPT quantity
|
1
|
|
|
Output string number
|
1
|
|
|
Lightning protection
|
||
|
Test Category
|
Secondary protection
|
|
|
Nominal discharge current
|
20 years old
|
|
|
Maximum discharge current
|
40 years old
|
|
|
Voltage protection level
|
2.8 kV
|
3.8kv
|
|
Maximum continuous operating voltage Uc
|
630V
|
1050V
|
|
Polish
|
2P
|
3p
|
|
Structural features
|
Plug Push Module
|
|
|
system
|
||
|
Protection level
|
IP65
|
|
|
Output switch
|
DC isolating switch (standard) / DC circuit breaker (optional)
|
|
|
Photovoltaic DC fuse
|
standard
|
|
|
Photovoltaic surge protector
|
Standard
|
|
|
Monitoring module
|
Optional
|
|
|
Prevent diode
|
Optional
|
|
|
Box material
|
Polyvinyl chloride
|
|
|
Installation Method
|
Wall Mount Type
|
|
|
Operating temperature
|
-25℃~+55℃
|
|
|
Temperature rise
|
2000m
|
|
|
Allowable relative humidity
|
0-95%, non-condensing
|
|
|
Mechanical parameters
|
||
|
W * H * D
|
300*260*140
|
|
Certification
We are the factory
Mday New Energy
Independent production of accessories
 |
 |
 |
 |
Injection molding workshop automated assembly line assembly automated assembly line
Own test laboratory
We have test equipment Type tests are carried out in a purpose built test laboratory. The purpose of type tests is to prove the functional and rated characteristics of the MCB.
 |
 |
 |
| T1 (10/350 μs) and T2 (8/20 μs) tests | Functional characteristics of fuse 0.5A-3150A voltage test | Resistance test |
Solutions for PV plants with string inverters
Mday laboratory ensures the highest product quality Our laboratory is accredited according to international standards. It operates independently and is recognised by institutions, registration services, and other institutions and authorities. As a member of the CTDP program, Mday is regularly audited by TUV, especially about test methods, quality management and documentation. Our PV AC combiner boxes are tested according to IEC-61439 and are constructed on the basis of the test results as well as assembled for the specific application. This ensures that each of the requirements of the target application is fully met.
 |
 |
 |
| 1.Automated assembly line | 2.Robot Arm | 3.Product Testing |
 |
 |
 |
| 4.Laser or Pad Printing | 5.Packing | 6.DIY Box |
Frequently asked questions
Q: Are you a factory or a trading company?
A: We are a factory and can provide OEM, ODM according to your needs. Please confirm our factory video.
A: All your inquiries will be replied within 24 hours.
A:First of all, we select high-quality raw materials for all raw materials.
Thirdly, our quality control department is specialized in quality inspection of each process.
Finally, our products strictly follow the ISO9001 quality control system, and all products must be tested after production is completed.
Q: What is the difference between DC MCB and AC MCB?
A: DC MCB functions are the same as AC MCB. The arc in the DC circuit is difficult to interrupt and extinguish, so
the accessory configuration of the same product is much higher than that of the AC model.
Q: What about the delivery period?
A: At present, we do not have enough stock for all models.
